Quality & Testing

FARO ARM

Model	: Edge
Accuracy	: 0.0009in to 0.0025in
Probe	: 3mm & 6mm
Reach	: 4 feet

DSC

Manufacturer	: NETZSCH
Temperature range	: 170ºC to 600ºC
Heating rate	: 0.0001 to 100K/min
Cooling rate	: 20 K/min down to 100ºC

UTM

Manufacturer	: INSTRON
Capacity	: 100 KN
Type	: Electro Mechanical Single Range (Dual column floor mounted)
Testing Speed	: 0.000002 in/min to 40 in/min

NDT

Non-Destructive Testing (NDT)

KKCI currently has capability in ultra-sonic A-Scan, Non Destructive Inspection of composite parts. KKCI has 3 ASNT level II qualified inspectors, one of whom is certified as per NAS 410 level II for Ultrasonics. KKCI also has NDT consultants, UK., a NDT level III, inspection agency on retainership basis. Having this capability allows KKCI to speed parts through NDT inspection and assist in our on-time performance.

Dual Robotic UT C-scan

Fill DRS ACCUBOT UT Inspection System is the first of its kind Dual Robot based C-Scan equipment in India. The Inspection System is manufactured by Fill, Austria has a 14 axes Squirter Type 7 m long, 2.5 m wide, 4 m height Robotic Arm C-Scan System.

Type of C-Scan system	Dual Robotic type system
Manufacturer	Fill, Austria
Mode of C-scan inspection/ Inspection Techniques	Water-coupled C-Scan ultrasonic (UT) scanning using P-E (Pulse Echo) modes. Scanning using T-T (Though Transmission) modes.
Type of UT system	Squirter Technique
Inspection area: Length: (X) Width: (Y) Height: (Z)	Inspection area: Length: 7000mm Width: 2500mm Height: 2500mm
Number of axes	14 Axes

• KKCI currently has 1 NAS 410 qualified NDI level-3 inspector and 5 NDI level-2 inspectors.
• NDI level-3 support also extended by an external company, NDT Consultants UK which has an office in Bangalore, India.
